Shuttering plywood is vital in construction, prized for its strength, water resistance, and reusability. It enables precise, high-quality concrete structures by providing reliable formwork, ensuring both structural integrity and aesthetic appeal. Essential for both large commercial and residential projects, it is key to achieving efficient, successful concrete work.
Technical Specifications:
| Feature | Specification | Advantage |
|---|---|---|
| Core Material | Selected Hardwood (Eucalyptus, Birch) | High strength, stability, and screw-holding power |
| Face/Back | Phenolic Film (Brown/Black) | Excellent release, water resistance, smooth finish, chemical resistance |
| Glue Type | WBP (Weather & Boil Proof) Melamine | Superior waterproofing and bonding, withstands harsh site conditions |
| Density | Approx. 680-720 kg/m³ | Optimal strength-to-weight ratio |
| Moisture Content | 8-12% | Ensures dimensional stability |
| Thickness | 12mm, 15mm, 18mm, 21mm (±0.2mm) | Versatility for slabs, walls, columns, beams |
| Panel Size | 1220mm x 2440mm (Standard) | Efficient coverage, minimizes cutting waste |
| Custom Sizes Available | Tailored solutions for specific project needs | |
| Reuse Cycles | 20+ (depending on concrete mix & care) | Significant long-term cost savings |
| Certifications | FSC® (Optional), ISO 9001, CE Marking | Responsible sourcing, quality assurance, meets EU requirements |
Structure
Film faced plywood is structural plywood coated with a phenolic or melamine resin film on one or both sides.
Surface: Phenolic film (brown/black) or melamine (light).
Core: Multi-layered hardwood veneers with waterproof WBP glue.
Thickness: 12mm, 15mm, 18mm, 21mm (common for formwork).
Benefits
Perfect Concrete Finish: Ultra-smooth phenolic film surface ensures mirror-like concrete results every time.
Exceptional Durability: Withstands 20+ reuses under normal conditions, slashing your formwork costs.
Unmatched Water Resistance: WBP (Water Boiled Proof) glue and premium phenolic coating prevent delamination and swelling.
Structural Integrity: High-density hardwood core provides superior strength and rigidity for heavy concrete loads.
Lightweight & Easy Handling: Optimized weight reduces labor fatigue and speeds up installation.
Global Standards Compliance: Meets international specifications for construction formwork (BS, EN, JIS).
Products Application
High-rise buildings & commercial complexes
Bridges, dams & infrastructure projects
Precast concrete elements
Architectural concrete requiring Class A finishes
Residential construction
Foundations, walls, columns, beams, and slabs
Why Choose US
For your costs and profits
In a competitive market, competition can cut into your profits significantly. So we can either support you by lowering prices or break the competitive landscape with a differentiated new product.
- By streamlining the production process, we can offer top-notch products with lower expenditure.
- We really focus on continuous innovation to ensure every item is of top-notch quality with great potential for business growth.
For your quality
- In our industry, we've carefully picked a number of raw material suppliers. We can trace and guarantee the output of high-quality materials, so you can trust our products are always made with good stuff.
For any inquiries, product consultations, or after-sales support you may need, we are here to assist you!
You can reach us through the following channels:
