Plywood is distinguished as the superior choice among wood-based panels, boasting enhanced strength in pivotal testing categories: resistance to bending, tensile forces, compressive loads, and shear stress. Beyond its robust performance, plywood offers a significant weight advantage, often weighing up to 40% less than comparable wood-based panels of equivalent thickness. For decades, it has served as a preferred construction material in the building industry, solidifying its status as the material of choice for individual investors, developers, architects, and engineers alike.
| Parameter | Specification |
|---|---|
| Product Type | Anti-Slip Mesh Phenolic Film Faced Plywood |
| Thickness | 18mm (Nominal) |
| Panel Size | 1220mm x 2440mm (4ft x 8ft) - Standard |
| Surface Finish | Phenolic Resin Coated with Raised Mesh |
| Core Material | Hardwood (Specify: Eucalyptus/Birch/etc.) |
| Face/Back | Mesh Pattern (One/Both Sides - Specify) |
| Density | Approx. 680-750 kg/m³ (Typical) |
| Formaldehyde | E0/E1 (<0.5ppm) - CARB P2/TSCA Title VI Compliant |
| Moisture Content | 8-12% |
| Bending Strength | High (Meets relevant EN 314-2 / JIS standards) |
Products Description
Construction: Multi-ply hardwood core (Eucalyptus, Poplar, Birch, or mixed hardwoods - specify if known).
Surface: Permanent, deeply embossed, raised diamond or mesh pattern on one or both sides (specify).
Coating: High-grade phenolic resin film overlay for ultimate wear, chemical, and moisture resistance.
Thickness: 18mm (Nominal). Consistent thickness for reliable performance.
Size: Standard 1220mm x 2440mm (4ft x 8ft). Custom sizes available upon request (OEM welcome).
Core: Tightly layered, void-free construction ensures strength and screw-holding capability.
Edge: Sealed edges (standard or optional) for enhanced moisture protection.
Structure
Film faced plywood is structural plywood coated with a phenolic or melamine resin film on one or both sides.
Surface: Phenolic film (brown/black) or melamine (light).
Core: Multi-layered hardwood veneers with waterproof WBP glue.
Thickness: 12mm, 15mm, 18mm, 21mm (common for formwork).
Products Benefits
Unbeatable Safety
Permanent raised mesh pattern provides exceptional slip resistance, even in wet, oily, or greasy conditions. Reduce accidents & boost worksite safety.
Superior Durability
Hardwood core combined with tough phenolic resin coating withstands heavy impacts, abrasion, chemicals, and harsh weather.
Water & Weather Resistant
Phenolic resin seals the wood, protecting against moisture, rot, and delamination for long-lasting performance indoors or outdoors.
Heavy Load Bearing
18mm thickness offers excellent structural strength for demanding applications.
Standard export packaging: Bundled tightly and secured with steel/plastic strapping.
Protected with waterproof paper or plastic wrap.
Loaded onto strong wooden pallets.
20ft Container Capacity: Approx. 500-550 sheets (1220x2440mm). (Confirm exact qty based on packing method).
FCL & LCL options available. Professional handling ensured.
Products Images
 |
 |
 |
Why Choose Our Anti-Slip Mesh Plywood?
Premium Materials: We select only quality hardwood cores and high-performance phenolic resin.
Strict Quality Control: Every sheet undergoes inspection for consistency, strength, and surface integrity.
Proven Safety: The engineered mesh pattern delivers reliable traction year after year.
Export Expertise: We understand international shipping requirements and documentation.
Competitive Pricing: Superior value for industrial-grade performance and longevity.
Customization Options: Available sizes, edge sealing, branding (OEM), and packaging tailored to your needs.
